Asus WS X299 PRO/SE [25/142] Expansion slots

ASUS WS X299 PRO Series

1-7

Chapter 1

1.1.5 Expansion slots

Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay

causeyouphysicalinjuryanddamagemotherboardcomponents.

Slot No. Slot Description

1 PCIE3.0x16_1slot

2 PCIE3.0x16_2slot

3 PCIE3.0x4_1slot

4 PCIE3.0x16_3slot

5 PCIE3.0x16_4slot
