ASUS WS X299 PRO Series
1-31
Chapter 1
20. M.2 sockets (M.2_1(Socket 3); M.2_2(Socket 3))
ThesesocketsallowyoutoinstallM.2SSDmodules.
• M.2_1socketsupportsPCIe3.0x4andSATAmodeMKeydesignandtype2242/
2260/2280PCIeandSATAstoragedevices.
• M.2_2socketsupportsPCIe3.0x4MKeydesignandtype2242/2260/2280/22110
PCIestoragedevices.
• ThesesocketssupportIRST(Intel
®
RapidStorageTechnology).
• TheM.2_2socketsharesbandwidthwiththeU.2connector.AdjusttheBIOSsettings
touseU.2devices.
TheM.2SSDmoduleispurchasedseparately.
