37
Item
Part Name Q’TY
No.
1 FRONT CAP 1
2 GRIP (A) 1
3 RING 2
4 NEEDLE HOLDER 1
5 SPRING (A) 1
6 RETAINING RING D42 2
7 BALL HOLDER 1
8 GRIP (B) 1
9 GRIP (C) 1
10 STEEL BALL D6.35 4
11 SEAL LOCK HEX. SOCKET HD. BOLT M6 × 25 4
12 FRONT COVER 1
13 O-RING 1
14 O-RING (S-34) 1
15 NEEDLE ROLLER D8 × 20 2
16 RETAINER SLEEVE 1
17 DAMPER (A) 1
18 HAMMER HOLDER (A) 1
19 O-RING (S-25) 1
20 Ring (B) 1
21 SECOND HAMMER 1
22 DAMPER (C) 1
23 SLEEVE (A) 1
24 HAMMER HOLDER (B) 1
25 WASHER 1
26 DAMPER (B) 1
27 HAMMER HOLDER (C) 1
28 STRIKER 1
29 O-RING 1
30 CYLINDER 1
31 SLIDE SLEEVE 1
32 SPRING (B) 1
33 O-RING 1
34 PISTON PIN 1
35 PISTON 1
36 CONNECTING ROD 1
37 RETAINING RING FOR D10 SHAFT 1
38 FEATHER KEY 4 × 4 × 10 1
39 SEAL LOCK HEX. SOCKET HD. BOLT M5 × 16 4
40 CRANK COVER 1
41 O-RING 1
42 CRANK SHAFT 1
43 RETAINING RING FOR D40 HOLE 1
44 O-RING (S-40) 1
45 BALL BEARING 6203DDCMPS2L 1
46 OIL SEAL 1
47 CYLINDER CRANK CASE 1
48 SEAL LOCK HEX. SOCKET HD. BOLT M6 × 45 4
49 HEX. SOCKET HD. BOLT (W/FLANGE) M5 × 12 1
50 HOOD 1
51 LEAF SPRING 1
52 SPRING DUMPER (A) 1
53 WASHER 1
54 SEAL LOCK HEX. SOCKET HD. BOLT M4 × 10 1
55 NEEDLE ROLLER 4
56 SEAL LOCK HEX. SOCKET HD. BOLT M5 × 22 1
57 RUBBER SHEET (C) 1
58 WEIGHT (B) 1
59 WEIGHT (A) 1
60 FIRST GEAR 1
61 NEEDLE BEARING (M661) 1
62 GEAR COVER ASS’Y 1
63 O-RING 1
64 BALL BEARING 6201DDCMPS2L 1
65 DUST WASHER (B) 1
66 FAN 1
67 ARMATURE ASS’Y 1
68 BOLT M8 1
69 HANDLE HOLDER (B) 2
70 HANDLE HOLDER (A) 2
71 BAND 1
72 GRIP 1
73 SIDE HANDLE ASS’Y 1
74 RUBBER SHEET (A) 1
75 SPRING BUMPER (B) 1
76 BACK COVER 1
77 BELLOWS 1
78 HEX. SOCKET HD. BOLT (W/FLANGE) M5 × 30 2
79 NAME PLATE 1
80 TAPPING SCREW (W/FLANGE) D5 × 20 4
81 HANDLE (A) 1
82 DISTANCE PIECE (B) 4
83 SEAL LOCK HEX. SOCKET HD. BOLT M5 × 12 4
84 HANDLE (B) 1
85 TAPPING SCREW (W/FLANGE) D4 × 25 3
86 HANDLE DAMPER 4
87 HANDLE SHAFT 1
88 HOLDER 1
89 HANDLE DAMPER 4
90 TRANSATORY UNIT 1
91 SWITCH (B) (1P SCREW TYPE) W/LOCK 1
92 WASHER M4 1
93 TERMINAL 1
94 VINYL TUBE 1
95 INTERNAL WIRE 1
96 NOISE SUPPRESSOR 1
97 SUPPORT (B) 1
98 INTERNAL WIRE 1
99 TAPPING SCREW (W/FLANGE) D4 × 16 2
100 CORD CLIP 1
101 CONNECTOR 50091 1
102 PILLAR TERMINAL 1
103 CONNECTOR 1
104 CORD ARMOR 1
105 CORD 1
106 FAN GUIDE 1
107 HEX. HD. TAPPING SCREW D5 × 55 2
108 STATOR ASS’Y 110V 1
109 BRUSH TERMINAL 2
110 TERMINAL M4.0 1
111 WASHER (A) 1
112 BALL BEARING 608VVC2PS2L 1
113 BEARING HOLDER 1
114 HOUSING ASS’Y 1
115 SPRING BASE 1
116 BRUSH CAP 2
117 CARBON BRUSH (AUTO STOP TYPE) 2
118 BRUSH HOLDER 2
119 HEX. SOCKET SET SCREW M5 × 82
120 TAIL COVER 1
121 TAPPING SCREW (W/FLANGE) D5 × 20 2
122 COVER (A) 1
501 BULL POINT (SDS MAX) 280L 1
502 CASE 1
Item
Part Name Q’TY
No.
09Back_H45MRY_EE 6/22/07, 15:4837
