21. Auto Tile Matrix
21.1 Auto Tile Matrix Execute
This command is used in order to activate the Auto Tile Matrix Setup.
1) The controller requests the monitor to execute Auto Tile Matrix
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'1'-'2'
STX-'C'-'A'-'0'-'3'-'0'-'1'-
HM-VM-PID-SEL-TMEM-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'1'-'2'(31h, 32h): Message length (18bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'3' (43h, 41h, 30h, 33h): Auto Tile Matrix Command
'0'-'1' (30h, 31h): Execution
HM: HORIZONTAL MONITORS
01h (30h, 31h) - 10h (31h, 30h)
VM: VERTICAL MONITORS
01h (30h, 31h) - 10h (31h, 30h)
PID: PETTERN ID
01h (30h, 31h) *Fixed
SEL: CURRENT INPUT SELECT
VGA(RGB) : 01h (30h, 31h) *1
DVI : 03h (30h , 33 h) * 1
VI DEO : 05h (30h , 35 h) * 1
VG A(YPbPr) : 0Ch (30h, 43h) *1
OPTION : 0Dh (30h, 44h)
DisplayPort1 : 0Fh (30h, 46h)
DisplayPort2 : 10h (31h, 30h)
HDMI 1 : 1 1 h ( 3 1h , 31 h )
HD MI2 : 12h (31h , 32 h)
HD MI3 : 82h (38h , 32 h) * 2
MP : 87h (38h , 37 h)
CO MPUTE MODULE : 87h (38h, 37h)
*1 Available on P404/ P484/ P554/ V404/ V484/ V554/ V404-T/ V484-T/ V554-T
*2 Not available on P404/ P484/ P554/ V404/ V484/ V554/ V404-T/ V484-T/ V554-T
TMEM: TILE MATRIX MEM
COMMON : 00h (30h, 30h)
INPUT : 01h (30h, 31h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refe r to the sec tion 4.3 “Ch eck code ” fo r a BCC calculation.
Delimiter
CR (0Dh): End of packet
