28.2 Emergency Contents Delete
This command is used in order to stop Emergency Contents.
1) The controller requests the monitor to set Security password.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
STX-'C'-'A'-'1'-'F'-'0'-'0'-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h,38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'1'-'F' (43h, 41h, 31h, 46h): Emergency Contents Command
'0'-'0' (30h, 30h): Delete
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refe r to the sec tion 4.3 “Ch eck code ” fo r a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a written in result.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'B'-'1'-'F'-'0'-'0'-ST-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'1'-'F' (43h, 42h, 31h, 46h): Emergency Contents Reply Command
'0'-'0' (30h, 31h): Delete
ST: Error Status
00h: No E rror
01h : Er ror
ET X (0 3h): End of Mess age
Ch eck code
BC C: B lock Che ck C ode
Re fer to t he s ecti on 4 .3 “C heck cod e” f or a BCC calculation.
Delimiter
CR (0Dh): End of packet
