24. Security Enable
24.1 Security Enable Read
This command is used in order to read the Security Enable.
1) The controller requests the monitor to read Security Enable
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
STX-'C'-'A'-'0'-'C'-'0'-'2'-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'C' (43h, 41h, 30h, 43h): Security password Command
'0'-'2' (30h, 32h): Enable Read
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refe r to the sec tion 4.3 “Ch eck code ” fo r a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Security Enable to the controller.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'B'-'0'-'C'-'0'-'2'-EN-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'C'-'0'-'2' (43h, 42h, 30h, 41h, 30h, 32h): Get Security Enable Disable Reply
EN: Status
00h: Disa ble
01h : En able
ET X (0 3h): End of Mess age
Ch eck code
BC C: B lock Che ck C ode
Re fer to t he s ecti on 4 .3 “C heck cod e” f or a BCC calculation.
Delimiter
CR (0Dh): End of packet
