Nec MultiSync V554 PG (Protective Glass) [35/141] Equalizer 1
![Nec MultiSync V554 PG (Protective Glass) [35/141] Equalizer 1](/views2/1375342/page35/bg23.png)
(35/139)
Item
OP code
page
OP code Parameter Remarks
SUPER
INPUT1 10h CEh 0: No mean
1: VGA(RGB) *1
3: DVI *1
5: VIDEO *1
12(0Ch): YGA(YPbPr) *1
13(0Dh): OPTION
15(0Fh): DisplayPort1
16(10h): DisplayPort2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3 *2
135(87h): MP
136(88h): COMPUTE MODULE
INPUT2 10h CFh
TERMINAL SETTING
DVI MODE *1 02h CFh 0: No mean
1: DVI-PC
2: DVI-HD
VGA MODE *1 10h 8Eh 0: No mean
1: RGB
2: YPbPr
SYNC TYPE *1 11h 95h 0: No mean
1: H/V SYNC
2: SOG
3: AUTO
DisplayPort 10h F1h/F2h Select target DPORT.
(F1h)
0: No mean
1: DPORT
2: DPORT2
3: DPORT3
Read / Write status of
target DPORT.(F2h)
0: No mean
1: 1.1a
2: 1.2
HDMI SIGNAL 10h 40h 0: No mean
1: EXPAND
2: RAW
EQUALIZER *1
SLOT2 11h 90h 0: Low
|
7: High
DisplayPort1 11h 91h 0: Low
|
7: High
HDMI 11h 68h 0: No mean
1: MODE1
2: MODE2
VIDEO LEVEL 10h 40h 0: No mean
1: EXPAND
2: NORMAL
3: AUTO
RESET
(MULTI INPUT)
02h CBh 0: No mean
6: Reset MULTI INPUT
Category
Momentary
OSD
LANGUAGE 00h 68h 0: No mean
1: ENGLISH
2: GERMAN
3: FRENCH
4: SPANISH
5: JAPANESE
6: ITALIAN
7: SWEDISH
9: RUSSIAN
14(0Eh): CHINESE
OSD Language
