(39/139)
Item
OP code
page
OP code Parameter Remarks
POWER 10h D5h 0: No mean
1: UNLOCK
2: LOCK
VOLUME 10h D6h 0: No mean
1: UNLOCK
2: LOCK
MIN VOL 10h D7h 0 (whisper)
|
100(64h) (laud)
MAX VOL 10h D8h 0 (whisper)
|
100(64h) (laud)
INPUT 10h D9h 0: No mean
1: UNLOCK
2: LOCK
UNLOCK SELECT 10h DAh 0: No mean
1: VGA(RGB) *1
3: DVI *1
5: VIDEO *1
12(0Ch): YGA(YPbPr) *1
13(0Dh): OPTION
15(0Fh): DisplayPort1
16(10h): DisplayPort2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3 *2
135(87h): MP
136(88h): COMPUTE MODULE
10h DBh
10h DCh
CHANNEL 10h D9h 0: No mean
1: UNLOCK
2: LOCK
KEY LOCK SETTING
MODE SELECT 11h 6Ah 0: No mean
1: UNLOCK
2: ALL LOCK
3: CUSTOM LOCK
POWER 11h 6Bh 0: No mean
1: UNLOCK
2: LOCK
VOLUME 11h 6Ch 0: No mean
1: UNLOCK
2: LOCK
MIN VOL 11h 6Dh 0 (whisper)
|
100(64h) (laud)
MAX VOL 11h 6Eh 0 (whisper)
|
100(64h) (laud)
INPUT 11h 6Fh 0: No mean
1: UNLOCK
2: LOCK
CHANNEL 10h D9h 0: No mean
1: UNLOCK
2: LOCK
