(138/139)
28. Emergency Contents
This function which plays files in the EMRGENCY CONTENTS folder in the root folder on SD card
automatically using MEDIA PLAYER function.
During playing, a display prohibits operation except power off.
Create “EMERGENCY CONTENTS” folder in a route folder.
"Display command" starts playing, and "Delete command" stops playing.
28.1 Emergency Contents Display
This command is used in order to display Emergency Contents.
1) The controller requests the monitor to display Emergency Contents.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'8'
STX-'C'-'A'-'1'-'F'-'0'-'1'-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'8'(30h, 38h): Message length (8byte)
Message
STX (02h): Start of Message
'C'-'A'-'1'-'F' (43h, 41h, 31h, 46h): Emergency Contents Command
'0'-'1' (30h, 32h): Display
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refe r to the sec tion 4.3 “Ch eck code ” fo r a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies Security Enable to the controller.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'B'-'1'-'F'-'0'-'1'-ST-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h,41h): Message length (10byte)
Message
STX (02h): Start of Message
'C'-'B'-'1'-'F' (43h, 42h, 31h, 46h): Emergency Contents Reply Command
'0'-'1' (30h, 32h): Display
ST: Status
00h: No E rror
01h : Er ror
ET X (0 3h): End of Mess age
