(38/139)
Item
OP code
page
OP code Parameter Remarks
HEAT STATUS
FAN1/2/3 02h 7Ah
/7Bh
Select target FAN. (7Ah)
0: No mean
1: FAN#1
2: FAN#2
3: FAN#3
Read status of target
FAN.(7Bh)
0: OFF
1: ON
2: ERROR
Read Only
BACKLIGHT Refer to Chapter 13 (Self-diagnosis status read)
TEMPERATURE
SENSOR1/2/3
02h 79h
Return value is 2’s
complement.
(0.5°C
step)
Offset
affects to a
selected
sensor.
Select
sensor
(Page02h
OPcode78h)
1 : SENSOR #1
2 : SENSOR #2
3 : SENSOR #3
SCREEN SAVER
GAMMA 02h DBh 0: No mean
1: OFF
2: ON
BACKLIGHT 02h DCh 0: No mean
1: OFF
2: ON
MOTION
INTERVAL 02h DDh 0: OFF(0s)
|
90(5Ah): 900s
10s/step
ZOOM 10h 35h 0 : 95%
|
5 : 100%
|
10(0Ah) : 105%
SIDE BORDER COLOR 02h DFh 0: Black
|
100(64h): White
POWER ON DELAY
DELAY TIME 10h CBh 0: (small)
|
100(64h): (large)
LINK TO ID 10h BCh 0: No mean
1: OFF
2: ON
RESET
(DISPLAY PROTECTION)
02h CBh 0: No mean
9: Reset
Display Protection
category
Momentary
CONTROL
IP ADDRESS SETTING N/A
CHANGE PASSWORD N/A
SECURITY Refer to Chapter 24
IR LOCK SETTING
MODE SELECT 10h D4h 0: No mean
1: UNLOCK
2: ALL LOCK
3: CUSTOM LOCK
The
following
commands can
also be used.
OP code page
02h
OP code 3Fh
Parameter
0: No mean
1: NORMAL
4: LOCK
