Nec MultiSync V554 PG (Protective Glass) [107/141] Auto tile matrix monitors write
![Nec MultiSync V554 PG (Protective Glass) [107/141] Auto tile matrix monitors write](/views2/1375342/page107/bg6b.png)
(107/139)
21.4 Auto Tile Matrix Monitors Write
This command is used in order to write the setting of H/V Monitors.
1) The controller requests the monitor to write H/V Monitors.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-
'0'-'A'-'0'-'C'
STX-'C'-'A'-'0'-'3'-'0'-'5'-HM-VM-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
Monitor ID: Specify the Monitor ID of which you want to change a setting.
Ex.) If Monitor ID is '1', specify 'A'.
'0' (30h): Message sender is the controller.
'A' (41h): Message type is "Command".
'0'-'C'(30h, 43h): Message length (12bytes)
Message
STX (02h): Start of Message
'C'-'A'-'0'-'3' (43h, 41h, 30h, 33h): Auto Tile Matrix Command
'0'-'5' (30h. 34h): Monitors Write
HM: H MONITORS
00h – 0Ah (30 h, 3 0h – 30h , 41 h)
VM: V MO NITO RS
0 0 h – 0 Ah ( 30 h , 3 0 h – 3 0h , 41 h )
ETX (03h ): E nd o f Me ssag e
Chec k co de
BCC: Blo ck C heck Cod e
Re f e r t o t h e s e c ti o n 4 . 3 “ C h ec k co d e ” f o r a BCC calculation.
Delimiter
CR (0Dh): End of packet
2) The monitor replies a written in result.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-
'B'-'0'-'A'
STX-'C'-'B'-'0'-'3'-'0'-'5'-ST-ETX BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.) When this byte is set to ‘A’, replying monitor’s ID is ‘1’.
'B' (42h): Message type is "Command reply".
'0'-'A'(30h, 41h): Message length (14bytes)
Message
STX (02h): Start of Message
'C'-'B'-'0'-'3' (43h, 42h, 30h, 33h): Auto Tile Matrix reply
'0'-'5' (30h, 34h): Monitors Write
ST: Error Status
No Er ror : 00 h (3 0h, 30h)
E r r or : 01 h (3 0h, 31h)
ETX (03h ): E nd o f Me ssag e
Chec k co de
BCC: Blo ck C heck Cod e
Refe r to the sec tion 4.3 “C heck cod e” f or a BCC calculation.
Delimiter
CR (0Dh): End of packet
