(36/139)
Item
OP code
page
OP code Parameter Remarks
MENU DISPLAY TIME 00h FCh 0-1: Do not set.
2: 10s
3: 15s
|
48(30h): 240s
5sec/step
OSD POSITION
X 02h 38h 0: Left
|
255(FFh): Right
Y 02h 39h 0: Down
|
255(FFh): Up
INFORMATION OSD 02h 3Dh 0:Disable information OSD
3-10(0Ah):
OSD timer [seconds]
OSD TRANSPARENCY 02h B8h 0: No mean
1: OFF
2: ON
OSD ROTATION 02h 41h 0: Landscape
1: Rotated
KEY GUIDE 11h 7Ah 0: No mean
1: OFF
2: ON
MEMO 10h BAh 0: No mean
1: Display a Memo
2: Undisplay a Memo
INPUT NAME Refer to chapter 20
NAME RESET
CLOSED CAPTION 10h 84h 0: No mean
1: OFF
2: CC1
3: CC2
4: CC3
5: CC4
6: TT1
7: TT2
8: TT3
9: TT4
RESET
(OSD)
02h CBh 0: No mean
7: Reset
OSD category
Momentary
MULTI DISPLAY
AUTO TILE MATRIX SETIP Refer to chapter 21
SETTING COPY Refer to Chapter 23
TILE MATRIX
H MONITOR 02h D0h 0: No mean
1
|
10(0Ah)
Number
of H-
division
V MONITOR 02h D1h 0: No mean
1
|
10(0Ah)
Number
of V-
division
POSITION 02h D2h 0: No mean
1
|
100(64h)
TILE COMP 02h D5h 0: No mean
1: NO
2: YES
H SIZE 11h 96h 0: Small
|
200(C8h): Large
