(40/139)
Item
OP code
page
OP code Parameter Remarks
DDC/CI 10h BEh 0: No mean
1: OFF
2: ON
PING N/A
IP ADDRESS RESET N/A
AUTO DIMMING
AUTO BRIGHTNESS 02h 2Dh 0: OFF
1: ON
BACKLIGHT DIMMING *2
11h 4Eh 0: No mean
1: OFF
2: ON
ROOM LIGHT SENSING
MODE 10h C8h 0: No mean
1: OFF
2: MODE1
3: MODE2
BACKLIGHT SETTING
MAX LIMIT 10h C9h 0 – 100(64h)
IN BRIGHT 10h 33h
0 – 100(64h)
IN DARK 10h 34h 0 – 100(64h)
SENSING LUX 02h B4h Current Illuminance read Read only
HUMAN SENSING
MODE 10h 75h 0: No mean
1: DISABLE
2: AUTO OFF
4: CUSTOM
BACKLIGHT
ON/OFF 10h DDh 0: No mean
1: Off
2: On
BACKLIGHT 10h C6h 0: dark
|
100(64h): light
VOLUME
ON/OFF 10h DEh 0: No mean
1: Off
2: On
VOLUME 10h C7h 0: whisper
|
100(64h): loud
INPUT SELECT
ON/OFF 10h DFh/D0h 0: No mean
1: Off
2: On
INPUT 10h D0h 0: No mean
1: VGA(RGB) *1
3: DVI *1
5: VIDEO *1
12(0Ch): YGA(YPbPr) *1
13(0Dh): OPTION
15(0Fh): DisplayPort1
16(10h): DisplayPort2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3 *2
135(87h): MP
136(88h): COMPUTE MODULE
