![Nec MultiSync V554 PG (Protective Glass) [41/141] Internal pc](/views2/1375342/page41/bg29.png)
(41/139)
Item
OP code
page
OP code Parameter Remarks
WAITING TIME 10h 78h 30(1Eh): short
|
600(258h): long
*1step: 1sec.
POWER INDICATOR
POWER INDICATOR 02 BEh 0: No mean
1: Off
2: On
SCHEDULE INDICATOR 11h 71h 0: No mean
1: Off
2: On
INTELLI WIRELESS DATA 10h ECh 0: No mean
1: OFF
2: ON
USB
TOUCH POWER 11h 72h 0: No mean
1: OFF
2: ON
EXTERNAL CONTROL 11h 73h 0: No mean
1: OFF
2: ON
PC SOURCE 11h 74h 0: No mean
1: AUTO
2: EXTERNAL PC
3: OPTION
4: C MODULE
USB POWER 11h 75h 0: No mean
1: ON
2: AUTO
CEC
CEC 11h 76h 0: No mean
1: OFF
2: ON
AUTO TURN OFF 11h 77h 0: No mean
1: NO
2: YES
AUDIO RECEIVER 11h 78h 0: No mean
1: NO
2: YES
SEARCH DEVICE 11h 79h 0: No mean
1: NO
2: YES
RESET
(CONTROL)
02h CBh 0: No mean
12(0Ch): Reset Control
Category
Momentary
OPTION
OPTION POWER 10h
41h
0: No mean
1: OFF
2: ON
3: AUTO
AUDIO 10h B0h 0: No mean
1: ANALOG
2: DIGITAL
INTERNAL PC
OFF WARNING 10h C0h 0: No mean
1: OFF
2: ON
AUTO OFF 10h C1h 0: No mean
1: OFF
2: ON
START UP PC 10h C2h 0: No mean
1: Execute
