Nec MultiSync V554 PG (Protective Glass) [37/141] Display protection
![Nec MultiSync V554 PG (Protective Glass) [37/141] Display protection](/views2/1375342/page37/bg25.png)
(37/139)
Item
OP code
page
OP code Parameter Remarks
V SIZE 11h 97h 0: Small
|
200(C8h): Large
H ADJUSTMENT 11h 98h 0: Left
|
200(C8h): Right
V ADJUSTMENT 11h 99h 0: Down
|
200(C8h): Up
ENABLE 02h D3h 0: No mean
1: NO
2: YES
TILE MATRIX MEM 10h 4Ah 0: No mean
1: COMMON
2: INPUT
MONITOR ID 02h 3Eh 1-100:ID
GROUP ID 10h 7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
|
1023(3FFh):Group
ABCDEFGHIJ
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
AUTO ID Refer to chapter 19
AUTO ID RESET Refer to chapter 19
RESET
(MULTI DISPLAY)
02h CBh 0: No mean
8: Reset
Multi Display
Category
Momentary
DISPLAY PROTECTION
POWER SAVE Refer to Chapter 22
POWER SAVE MESSAGE11h 11h 7Bh 0: No mean
1: OFF
2: ON
FAN CONTROL
COOLING FAN 02h 7Dh 0: No mean
1: AUTO
2: ON
FAN SPEED 10h 3Fh 0: No mean
1: HIGH
2: LOW
SENSOR1 10h E0h/E1h E0h: Set centigrade
0 – 65535(FFFFh)
E1h: Set
offset from max.
value
0 – 10(0Ah)
SENSOR2 10h E2h/E3h E2h: Set centigrade
0 – 65535(FFFFh)
E3h: Set
offset from max.
value
0 – 10(0Ah)
SENSOR3 10h E4h/E5h E4h: Set centigrade
0 – 65535(FFFFh)
E5h: Set
offset from max.
value
0 – 10(0Ah)
