(20/139)
5.5.2 Get Timing Report and Timing reply.
The controller requests the monitor to report the displayed image timing.
Send "07"(30h, 37h) as Get Timing Report command.
Complete "Get Timing Report" command packet as follows;
ASCII: 01h-30h-41h-30h-41h-30h-34h-02h-30h-37h-03h-CHK-0Dh
SOH-'0'-'A'-'0'-'A'-'0'-'4'-STX-'0'-'7'-ETX-CHK- CR
The monitor replies status as the following format;
SS: Timing status byte
Bit 7 = 1: Sync Frequency is out of range.
Bit 6 = 1: Unstable count
Bit 5-2 Rese rved (Do n't care )
Bi t 1 1:P osit ive Hori zont al s ync pola rity
0: Nega tive Hor izon tal sync polarity.
Bit 0 1:P osit ive Vert ical syn c po lari ty.
0: Nega tive Ver tica l sy nc polarity.
H Freq: Horizontal Frequency in unit 0.01kHz
V Freq: Vertical Frequency in unit 0.01Hz
Ex.) When H Freq is '1''2''A''9' (31h, 32h, 41h, 39h), it means 47.77kHz.
STX
Command code
ETX
'0' '7'
STX
Command SS H Freq. V Freq. ETX
'4'
'E'
Hi
Lo
MSB
LSB
MSB
LSB
