(33/139)
Item
OP code
page
OP code Parameter Remarks
HOLIDAY SETTINGS Refer to chapter 11
WEEKEND SETTINGS Refer to chapter 12
DATE & TIME Refer to chapter 9
DAYLIGHT SAVING Refer to chapter 17
OFF TIMER 02h 2Bh 0: Off
1: 1 hour
|
24(18h): 24 hour
1 hour/step
RESET
(SCHEDULE)
02h CBh 0: No mean
5: Reset
Schedule category
Momentary
MULTI INPUT
KEEP MULTI PICTURE MODE 10h 82h 0: No mean
1: OFF
2: ON
MULTI PICTURE MODE 02h 72h 0: No mean
1: OFF
2: PIP
5: PBP (PBP1)
7: PBP2 *2
8: PBP3 *2
ACTIVE PICTURE
ACTIVE 11h 0Bh 0: No mean
1: PICTURE1
2: PICTURE2
3: PICTURE3 *2
4: PICTURE4 *2
ACTIVE FRAME 11h 0Dh 0: No mean
1: OFF
2: ON
INPUT SELECT
PICTURE1 11h 0Eh 0: No mean
1: VGA(RGB) *1
3: DVI *1
5: VIDEO *1
12(0Ch): YGA(YPbPr) *1
13(0Dh): OPTION
15(0Fh): DisplayPort1
16(10h): DisplayPort2
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3 *2
135(87h): MP
136(88h): COMPUTE MODULE
PICTURE2 11h 0Fh
PICTURE SIZE 10h B9h 0(small)
|
80(large)
PICTURE POSITION
X 02h 74h 0: left
|
100(64h): right
Y 02h 75h 0: top
|
100(64h): bottom
