![Nec MultiSync V554 PG (Protective Glass) [32/141] Audio delay](/views2/1375342/page32/bg20.png)
(32/139)
Item
OP code
page
OP code Parameter Remarks
AUDIO
VOLUME 00h 62h 0: whisper
|
100(64h): loud
BALANCE
BALANCE
00h 93h O: Left
|
30(1Eh):(Center)
|
60(3Ch): Right
00h 94h 0: No mean
1: MONAURAL
2: STEREO
SURROUND 02h 34h 0: No mean
1: OFF
2: ON
EQULIZER
TREBLE 00h 8Fh O: Min.
|
6:(Center)
|
12(0Ch): Max.
BASS 00h 91h 0: Min.
|
6:(Center)
|
12(0Ch): Max.
AUDIO INPUT 02h 2Eh 0: No mean
1: IN1
2: IN2 *1
4: HDMI1
6: OPTION
7: DisplayPort1
8: DisplayPort2
10(0Ah): HDMI2
11(0Bh): HDMI3 *2
13(0Dh): MP
14(0Eh): COMPUTE MODULE
MULTI PICTURE AUDIO 10h 80h 0: No mean
3: PICTURE1
4: PICTURE2
5: PICTURE3
6: PICTURE4
LINE OUT 10h 81h 0: No mean
1: FIXED
2: VARIABLE
AUDIO DELAY
AUDIO DELAY 10h CAh 0: No mean
1: OFF
2: ON
DELAY TIME 10h CBh 0: (small)
|
100(64h): (large)
RESET
(AUDIO)
02h CBh 0: No mean
4: Reset
Audio category
Momentary
SCHDULE
SCHEDULE
ENABLE 02h E5h 0: No mean
1: No.1 Enable
|
30(1Eh): No.30 Enable
DISABLE 02h E6h 0: No mean
1: No.1 Disable
|
30(1Eh): No.30 Disable
SCHEDULE SETTINGS Refer to chapter 10
