Nec MultiSync V554 PG (Protective Glass) [42/141] Compute module
![Nec MultiSync V554 PG (Protective Glass) [42/141] Compute module](/views2/1375342/page42/bg2a.png)
(42/139)
Item
OP code
page
OP code Parameter Remarks
FORCE QUIT 10h C3h 0: No mean
1: Execute
SLOT2 CH SETTING 11h 62h 0: No mean
1: AUTO
2: CH1
3: CH2
SLOT2 CH SELECT 11h 63h 0: No mean
1: TDMS
2: DisplayPort
RESET
(OPTION)
02h CBh 0: No mean
10(0Ah): Option Category
SYSTEM
MONITOR INFORMATION
MODEL NAME Refer to chapter 14
SERIAL Refer to chapter 14
CARBON SAVINGS
10h 10h
(g)
/11h
(kg)
0 – 999(3E7h)(g)
0 – 65535(FFFF
ｈ
)(kg)
Read Only
CARBON USAGE 10h 26h
(g)
/27h
(kg)
0 – 999(3E7
ｈ
)(g)
0 – 65535(FFFF
ｈ
)(kg)
Read Only
FIRMWARE Refer to chapter 18
MAC ADDRESS Refer to Chapter 25
FACTORY RESET 02h CBh 0: No mean
1: Factory Reset
Momentary
COMPUTE MODULE
POWER
POWER SUPPLY 11h 7Ch 0: No mean
1: OFF
2: ON
AUTO POWER ON 11h 7Dh 0: No mean
1: DISABLE
2: ENABLE
SERVICE MENU
SETTING LOCK Refer to Chapter 27
USB BOOT MODE 11h 7Eh 0: No mean
1: DISABLE
2: ENABLE
It can be used
by turning OFF
SETTING LOCK
using SETTING
LOCK command.
IR SIGNAL 11h 7Fh 0: No mean
1: DISABLE
2: ENABLE
MONITOR CONTROL 11h 80h 0: No mean
1: DISABLE
2: ENABLE
SHUTDOWN SIGNAL 11h 81h 0: No mean
1: DISABLE
2: ENABLE
POWER OFF DELAY 11h 82h 30(1Eh): short
|
600(258h): long
*1step: 1sec.
WDT
WDT 11h 9Bh 0: No mean
1: Disable
2: Enable
START UP
TIME 11h 9Ch 0: No mean
1 (short)
|
30 (1Eh) (long)
*1step: 10sec.
