(43/139)

Item

OP code

page

OP code Parameter Remarks

RERIOD TIME 11h

9Dh

0: No mean

1 (short)

30 (1Eh) (long)

*1step: 10sec.

CHANGE PASSWORD N/A

Other

MUTE 00h 8Dh 0: UNMUTE (Set only)

1: MUTE

2: UNMUTE

SCREEN MUTE 10h B6h 0: No mean

1: SCREEN MUTE ON

2: SCREEN MUTE OFF

MTS 02h 2Ch 0: No mean

1: Main

2: Sub

3: Main + Sub

This

operation

requires

supported

option TV

tuner.

SOUND 02h 34h 0: No mean

1: Off

2: ON

Same as

‘SURROUND’

STILL CAPTURE 02h 76h 0: OFF

1: CAPTURE

Momentary

SIGNAL INFORMATION 02h EAh 0: No mean

1: OFF

2: ON

TV-CHANNEL UP/DOWN 00h 8Bh 0: No mean

1: UP

2: DOWN

This

operation

requires

supported

option TV

tuner.

*1 Available on P404/ P484/ P554/ V404/ V484/ V554/ V404-T/ V484-T/ V554-T

*2 Not available on P404/ P484/ P554/ V404/ V484/ V554/ V404-T/ V484-T/ V554-T
