Item OP

code

page

OP code Parameter Remarks

GREEN y 10h 58h 500(01F4h): 0.500

900(0384h): 0.900

BLUE x 10h 59h 0: 0.000

250(00FAh): 0.250

BLUE y 10h 5Ah 0: 0.000

150(0096h): 0.150

COLOR VISION EMU 10h 5Bh 0: No mean

1: OFF

2: P

3: D

4: T

5: GRAY

UNIFORMITY 02h FFh 0: OFF

METAMERISM 10h 5Ch 0: No mean

1: OFF

2: ON
