Page 10
Physical Data - SWR 2602 to 4402 - HFC 407C
SWR Models - HFC 407C 2602 3002 3402 3802 4202 4402
Cooling capacity (1) kW 701.1 789.8 889.6 1028.4 1078.5 1147.9
Power input (compressors)
(1) kW 186.2 209.5 235.5 272.1 292.2 321.3
Heat rejection (1) kW 887.4 999.3 1125.2 1300.5 1370.8 1469.1
Power supply
400 V / 3 Ph / 50 Hz
Number of refrigerant circuits 2 2 2 2 2 2
Capacity steps % 25/50/63/75/87/100
REFRIGERANT
Type
HFC 407C
COMPRESSORS
Type
Screw
Number 2 2 2 2 2 2
Startup type Star/∆
Oil type Polyester POE
EVAPORATOR
Type
Shell and tube
Number 1 1 1 1 1 1
Water flow
l/s 33.5 37.7 42.5 49.1 51.5 54.8
Water pressure drop kPa
51.3 53.0 63.4 86.5 95.1 107.7
Water content
litres 221.7 206.5 184.4 222.2 222.2 222.2
WATER CONNECTIONS - EVAPORATOR
Type
Victaulic
Inlet/Outlet diameter DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8")
WEIGHT
Shipping weight kg 2663 2712 2825 3495 3535 3395
Operating weight kg 2885 2919 3009 3717 3757 3617
DIMENSIONS
Length
mm 4210 4210 4210 4210 4210 4210
Width mm 1610 1610 1610 1610 1610 1610
Height mm 2050 2050 2050 2050 2050 2050
SOUND LEVELS
Sound power level dB(A) 95 96 97 98 98 98
Sound pressure level (2) dB(A) 76 77 78 79 79 79
WEIGHT - LN VERSION
Shipping weight kg 3063 3112 3225 3895 3935 3795
Operating weight kg 3285 3319 3409 4117 4157 4017
SOUND LEVELS - LN VERSION
Sound power level dB(A) 90 91 92 93 93 93
Sound pressure level (2) dB(A) 71 72 73 74 74 74
WEIGHT - ELN VERSION
Shipping weight kg 3183 3232 3345 4015 4055 3915
Operating weight kg 3405 3439 3529 4237 4277 4137
SOUND LEVELS - ELN VERSION
Sound power level dB(A) 82 83 84 85 85 85
Sound pressure level (2) dB(A) 63 64 65 66 66 66
(1) Data based on : evaporator leaving water temperature of 7 °C and condensing temperature of 45 °C.
(2) At the distance of 1 meter on reflecting surface and in free field conditions.
