Page 7
Physical Data - SWS 1002 to 2202 - HFC 407C
SWS Models - HFC 407C 1002 1202 1402 1602 1902 2202
Cooling capacity (1) kW 290.5 312.6 346.9 393.8 489.6 599.6
Power input (compressors) (1) kW 81.3 87.3 97.9 111.7 135.6 161.6
Heat rejection (1) kW 371.8 399.9 444.8 505.4 625.2 761.2
Power supply
400 V / 3 Ph / 50 Hz
Number of refrigerant circuits 2 2 2 2 2 2
Capacity steps % 25/50/63/75/87/100
REFRIGERANT
Type
HFC 407C
Charge kg 59 63 70 80 99 122
COMPRESSORS
Type Screw
Number 2 2 2 2 2 2
Startup type P/W P/W P/W P/W P/W Star/∆
Oil type Polyester POE
EVAPORATOR
Type
Shell and tube
Number 1 1 1 1 1 1
Water flow
l/s 13.9 14.9 16.6 18.8 23.4 28.6
Water pressure drop kPa 45.4 52.5 31.1 40.0 42.7 37.5
Water content
litres 93.3 93.3 80.2 80.2 124.7 221.7
CONDENSERS
Type
Shell and tube
Number 2 2 2 2 2 2
Water flow
l/s 8.9 9.6 10.6 12.1 14.9 18.2
Water pressure drop kPa
44.0 50.9 59.8 62.8 72.2 54.5
Total water content
litres 28.4 28.4 28.4 30.8 49.4 62.4
WATER CONNECTIONS - EVAPORATOR
Type
Victaulic
Inlet/Outlet diameter DN 125 (5") DN 125 (5") DN 125 (5") DN 125 (5") DN 150 (6") DN 200 (8")
WATER CONNECTIONS - CONDENSERS
Type Female gas threaded
Inlet/Outlet diameter inch 2"1/2 2"1/2 2"1/2 2"1/2 3" 3"
WEIGHT
Shipping weight kg 1645 1659 2041 2067 2554 3005
Operating weight kg 1768 1780 2148 2176 2728 3288
DIMENSIONS
Length
mm 3795 3795 3795 3795 3795 4210
Width mm 1160 1160 1160 1160 1160 1610
Height mm 1910 1910 1910 1910 1910 2050
SOUND LEVELS
Sound power level dB(A) 94 94 94 94 95 95
Sound pressure level (2) dB(A) 76 76 75 75 76 76
WEIGHT - LN VERSION
Shipping weight kg 1955 1969 2351 2377 2864 3405
Operating weight kg 2077 2091 2460 2488 3038 3689
SOUND LEVELS - LN VERSION
Sound power level dB(A) 89 89 89 89 90 90
Sound pressure level (2) dB(A) 71 71 70 70 71 71
WEIGHT - ELN VERSION
Shipping weight kg 2045 2059 2441 2467 2954 3525
Operating weight kg 2167 2181 2550 2578 3128 3809
SOUND LEVELS - ELN VERSION
Sound power level dB(A) 81 81 81 81 82 82
Sound pressure level (2) dB(A) 63 63 62 62 63 63
(1) Data based on : evaporator leaving water temperature of 7 °C and condenser leaving water temperature of 35 °C.
(2) At the distance of 1 meter on reflecting surface and in free field conditions.
