Page 5
Operating Limits
Units SWS SWR
Chilled
Liquid
Liquid outlet
temperature
Water outlet
°C +5 to +15
Brine outlet °C +4 to -5
Temperature spread
K 3 to 8
Flow rate (1) l/s
Please refer to "Water Pressure Drops" Section
Pressure drop (1) kPa
Maximum operating pressure - Water side bar 10 10
Warm
Liquid
Water outlet temperature
°C
+30 to +50 °C with tower water
+15 to +30 °C with well water
Temperature spread
K
3 to 8 with tower water
15 with well water
Flow rate (1) l/s
Please refer to
"Water Pressure Drops" Section
Pressure drop (1) kPa
Maximum operating pressure - Water side bar 10
Units SWS SWR
Chilled
Liquid
Liquid outlet
temperature
Water outlet
°C +5 to +15
Brine outlet °C +4 to -3
Temperature spread
K 3 to 8
Flow rate (1) l/s
Please refer to "Water Pressure Drops" Section
Pressure drop (1) kPa
Maximum operating pressure - Water side bar 10 10
Warm
Liquid
Water outlet temperature
°C
+30 to +60 °C with tower water
+15 to +30 °C with well water
Temperature spread
K
3 to 8 with tower water
15 with well water
Flow rate (1) l/s
Please refer to
"Water Pressure Drops" Section
Pressure drop (1) kPa
Maximum operating pressure - Water side bar 10
Units with HFC 407C
(1) At nominal conditions.
Units with HFC 134a
(1) At nominal conditions.
