Physical Data - SWS 1602 to 2802 - HFC 134a
SWS Models - HFC 134a 1602 1902 2202 2212 2352 2502 2652 2802
Cooling Capacity (1) kW 271.8 362.4 440.0 529.3 564.7 600.0 639.2 678.4
Power Input (Compressors) (1) kW 63.1 76.3 92.3 112.6 120.4 128.1 135.4 142.8
Heat rejection (1) kW 334.9 438.7 532.4 641.9 685.0 728.1 774.7 821.2
Power supply
400 V / 3 Ph / 50 Hz
Number of refrigerant circuits 2 2 2 2 2 2 2 2
Capacity steps % 25/50/63/75/87/100
REFRIGERANT
Refrigerant type HFC 134a
Refrigerant Charge kg 46 61 74 52 55 59 63 66
COMPRESSORS
Type Screw
Number 2 2 2 2 2 2 2 2
Startup type P/W Y/∆
Oil type Polyester POE BSE170
EVAPORATOR
Type
Shell and tube
Number 1 1 1 1 1 1 1 1
Water flow
l/s 13.0 17.3 21.0 25.3 27.0 28.7 30.5 32.4
Water pressure drop kPa 44.4 54.4 53.7 42.2 40.5 45.7 56.3 63.4
Water content
litres 80.2 124.7 221.7 162 184 184 222 222
CONDENSER
Type
Shell and tube
Number 2 2 2 2 2 2 2 2
Water flow
l/s 8.0 10.5 12.7 15.3 16.4 17.4 18.5 19.6
Water pressure drop kPa
28.7 38.7 41.0 40.1 45.7 41.6 47.0 50.2
Water content (total)
litres 30.8 49.4 55.4 62 62 68 68 68
WATER CONNECTIONS - EVAPORATOR
Type
Victaulic
Inlet/Outlet diameter
DN 125 (5") DN 150 (6") DN 200 (8") DN 150 (6") DN 150 (6") DN 150 (6") DN 150 (6") DN 150 (6")
WATER CONNECTIONS - CONDENSERS
Type Female gas threaded
Inlet/Outlet diameter inch 2"1/2 3" 3" 3" 3" 3" 3" 3"
WEIGHT
Shipping weight kg 2067 2554 3005 3377 3470 3498 3592 3605
Operating weight kg 2144 2688 3212 3601 3717 3750 3882 3895
DIMENSIONS
Width mm 1160 1160 1610 1610 1610 1610 1610 1610
Height mm 1910 1910 2050 2050 2050 2050 2050 2050
Length
mm 3795 3795 4210 4210 4210 4210 4210 4210
SOUND LEVEL
Sound power level dB(A) 94 94 95 95 95 95 95 95
Sound pressure level (2) dB(A) 75 75 76 76 76 76 76 76
WEIGHT - LN VERSION
Shipping weight kg 2343 2826 3333 3777 3870 3898 3992 4005
Operating weight kg 2454 3000 3611 4001 4117 4150 4282 4295
SOUND LEVELS - LN VERSION
Sound power level dB(A) 89 89 90 90 90 90 90 90
Sound pressure level (2) dB(A) 70 70 71 71 71 71 71 71
WEIGHT - ELN VERSION
Shipping weight kg 2433 2916 3453 3927 4020 4048 4142 4155
Operating weight kg 2544 3090 3731 4151 4267 4300 4432 4445
SOUND LEVELS - ELN VERSION
Sound power level dB(A) 81 81 82 82 82 82 82 82
Sound pressure level (2) dB(A) 62 62 63 63 63 63 63 63
(1) Data based on : evaporator leaving water temperature of 7 °C and condenser leaving water temperature of 35 °C.
(2) At the distance of 1 meter on reflecting surface and in free field conditions.
