Electrical Data
SWS / SWR - HFC 407C
Models 1002 1202 1402 1602 1902 2202 2602 3002 3402 3802 4202 4402
UNITS
Nominal voltage 400 V ± 10% - 3 ph - 50 Hz
Nominal power input kW 92 98 114 130 157 189 223 246 269 296 316 393
Maximum power input kW 111 117 135 155 187 225 265 293 317 349 373 460
Nominal current A 157 175 203 232 280 338 397 440 480 529 564 701
Maximum current FLA A 164 192 248 280 336 392 450 490 540 600 668 800
Maximum starting current LRA A 360 440 367 449 613 455 512 546 642 753 829 875
External fuses A 200 250 315 315 400 500 500 630 630 630 800 1000
Wire cross area mm
2
120 120 185 185 2x150 2x150 2x185 2x185 2x185 2x240 2x240 2x300
COMPRESSORS (*)
Quantity 2 2 2 2 2 2 2 2 2 2 2 2
Nominal power input kW 46 49 57 65 79 95 111 123 135 148 158 197
Maximum power input kW 55 58 68 77 94 113 132 147 158 175 186 230
Nominal current A 79 87 102 116 140 169 199 220 240 264 282 351
Maximum current FLA A 82 96 124 140 168 196 225 245 270 300 334 400
Maximum starting current LRA A 303 373 280 351 495 318 354 374 453 543 595 595
Oil heater power input W 200 200 200 200 200 200 275 275 275 275 275 275
REFRIGERANT - WATER ANTIFREEZE HEATER(**)
Nominal voltage 230 V - 1 ph - 50 Hz
Nominal power input W 2x400
Tank antifreeze heater
W N.A.
SWS/R R134a 1602 1902 2202 2212 2352 2502 2652 2802 3012 3202 3412 3602 4212 4602 4802
POWER
Nominal voltage 400 V ± 10% - 3 ph - 50 Hz
Nominal power input kW 78.8 95 114.4 158 166 174 184 194 211 228 249 270 298 315 332
Maximum power input kW 109.6 132.4 159.4 220 230 240 251 262 286 310 359 408 408 426 444
Nominal current A 141 169 204 266 279 292 310 328 351 374 404 434 492 519 546
Maximum current FLA A 192 210 260 360 395 430 446 462 511 560 590 620 620 670 720
Maximum starting current LRA A 347.2 424.5 586 393 417.5 464.5 491.5 502.7 597.7 632 661 682 803 867 902
External fuses A 250 250 315 400 400 500 500 500 630 630 630 630 630 800 800
Wire cross area mm
2
120 120 185
2x150 2x150 2x150 2x185 2x150 2x185 2x185 2x185 2x185 2x185 2x240 2x240
COMPRESSORS (*)
Quantity 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Nominal power input - Comp. 1
kW 39.4 47.5 57.2 79 79 87 87 97 97 114 114 135 149 149 166
Nominal power input - Comp. 2
kW 39.4 47.5 57.2 79 87 87 97 97 114 114 135 135 149 166 166
Maximum power input - Comp. 1
kW 54.8 66.2 79.7 110 110 120 120 131 131 155 155 204 204 204 222
Maximum power input - Comp. 2
kW 54.8 66.2 79.7 110 120 120 131 131 155 155 204 204 204 222 222
Nominal current - Comp. 1 A 70 85 102 133 133 146 146 164 164 187 187 217 246 246 273
Nominal current - Comp. 2 A 70 85 102 133 146 146 164 164 187 187 217 217 246 273 273
Maximum current FLA - Comp. 1
A 96 105 130 180 180 215 215 231 231 280 280 310 310 310 360
Maximum current FLA - Comp. 2
A 96 105 130 180 215 215 231 231 280 280 310 310 310 360 360
Max. starting current LRA - Comp. 1
A 280 351 495 267 267 314 314 341 341 436 436 465 586 586 650
Max. starting current LRA - Comp. 2
A 280 351 495 267 314 314 341 341 436 436 465 465 586 650 650
Oil heater power input W 200 200 200 300 300 300 300 300 300 300 300 300 300 300 300
REFRIGERANT - WATER ANTIFREEZE HEATER(**)
Nominal voltage 230 V - 1 ph - 50 Hz
Nominal power input W 2x400
Tank antifreeze heater
W N.A.
SWS / SWR - HFC 134a
(*) Data given for one compressor.
(**) Available as option.
