Page 8
Physical Data - SWS 2602 to 4402 - HFC 407C
SWS Models - HFC 407C 2602 3002 3402 3802 4202 4402
Cooling capacity (1) kW 701.1 789.8 889.6 1028.4 1078.5 1147.9
Power input (compressors) (1) kW 186.2 209.5 235.5 272.1 292.2 321.3
Heat rejection (1) kW 887.4 999.3 1125.2 1300.5 1370.8 1469.1
Power supply
400 V / 3 Ph / 50 Hz
Number of refrigerant circuits 2 2 2 2 2 2
Capacity steps % 25/50/63/75/87/100
REFRIGERANT
Type
HFC 407C
Charge kg 142 160 181 209 219 233
COMPRESSORS
Type Screw
Number 2 2 2 2 2 2
Startup type Star/∆
Oil type Polyester POE
EVAPORATOR
Type
Shell and tube
Number 1 1 1 1 1 1
Water flow
l/s 33.5 37.7 42.5 49.1 51.5 54.8
Water pressure drop kPa 51.3 53.0 63.4 86.5 95.1 107.7
Water content
litres 221.7 206.5 184.4 222.2 222.2 222.2
CONDENSERS
Type
Shell and tube
Number 2 2 2 2 2 2
Water flow
l/s 21.2 23.9 26.9 31.1 32.7 35.1
Water pressure drop kPa
53.1 67.4 80.9 64.9 68.3 78.5
Total water content
litres 71.4 71.4 71.4 95.0 95.0 95.0
WATER CONNECTIONS - EVAPORATOR
Type
Victaulic
Inlet/Outlet diameter DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8") DN 200 (8")
WATER CONNECTIONS - CONDENSERS
Type Female gas threaded
Inlet/Outlet diameter inch 3" 3" 3" 4" 4" 4"
WEIGHT
Shipping weight kg 3259 3326 3460 4330 4380 4254
Operating weight kg 3552 3604 3716 4648 4696 4572
DIMENSIONS
Length
mm 4210 4210 4210 4210 4210 4210
Width mm 1610 1610 1610 1610 1610 1610
Height mm 2050 2050 2050 2050 2050 2050
SOUND LEVELS
Sound power level dB(A) 95 96 97 98 98 98
Sound pressure level (2) dB(A) 76 77 78 79 79 79
WEIGHT - LN VERSION
Shipping weight kg 3659 3726 3860 4730 4780 4654
Operating weight kg 3952 4004 4115 5047 5097 4971
SOUND LEVELS - LN VERSION
Sound power level dB(A) 90 91 92 93 93 93
Sound pressure level (2) dB(A) 71 72 73 74 74 74
WEIGHT - ELN VERSION
Shipping weight kg 3779 3846 3980 4850 4900 4774
Operating weight kg 4072 4124 4235 5167 5217 5091
SOUND LEVELS - ELN VERSION
Sound power level dB(A) 82 83 84 85 85 85
Sound pressure level (2) dB(A) 63 64 65 66 66 66
(1) Data based on : evaporator leaving water temperature of 7 °C and condenser leaving water temperature of 35 °C.
(2) At the distance of 1 meter on reflecting surface and in free field conditions.
