Page 29
SWS
Models
LWT
Evap.
(°C)
LWT Condenser (°C)
14/30 25/30 27/32 30/35 33/38
Well Water - 4 Pass Tower Water - 2 Pass Tower Water - 2 Pass Tower Water - 2 Pass Tower Water - 2 Pass
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
3012
5 694.5 140.6 835.1 704.0 141.2 845.2 690.9 146.1 836.9 670.5 153.8 824.3 649.0 162.2 811.2
6 716.0 142.2 858.2 727.2 142.2 869.5 713.9 147.2 861.1 693.1 155.0 848.1 671.2 163.5 834.7
7 737.5 143.7 881.2 751.0 143.2 894.2 737.1 148.3 885.4 716.0 156.2 872.2 693.8 164.7 858.5
8 758.9 145.3 904.3 775.4 144.1 919.5 761.6 149.2 910.8 739.5 157.4 896.9 716.7 166.0 882.7
9 780.4 146.9 927.3 799.4 145.3 944.7 785.4 150.4 935.8 763.3 158.5 921.9 740.1 167.3 907.3
10 801.9 148.4 950.3 823.6 146.4 970.1 809.5 151.6 961.1 787.2 159.8 947.0 763.6 168.6 932.2
11 823.4 150.0 973.4 848.2 147.6 995.7 833.8 152.8 986.6 811.3 161.0 972.4 787.5 169.9 957.4
12 844.9 151.6 996.4 870.8 148.6 1019.4 858.1 154.0 1012.1 835.5 162.3 997.8 811.4 171.2 982.6
13 866.3 153.1 1019.5 897.0 149.9 1046.9 882.5 155.3 1037.8 859.7 163.6 1023.3 835.4 172.5 1007.9
14 887.8 154.7 1042.5 921.0 151.1 1072.1 906.6 156.5 1063.0 883.8 164.9 1048.7 859.4 173.9 1033.3
15 909.3 156.2 1065.5 944.5 152.0 1096.6 930.2 157.5 1087.7 906.8 166.0 1072.8 881.7 175.1 1056.8
3202
5 760.9 152.8 913.7 771.3 153.3 924.7 756.9 158.7 915.6 734.6 167.1 901.7 711.0 176.2 887.2
6 784.4 154.5 938.9 796.8 154.5 951.3 782.1 159.9 942.0 759.3 168.4 927.7 735.4 177.6 912.9
7 808.0 156.2 964.1 822.8 155.6 978.4 807.6 161.1 968.7 784.4 169.7 954.2 760.1 179.0 939.1
8 831.5 157.9 989.3 849.5 156.6 1006.1 834.4 162.1 996.5 810.2 171.0 981.2 785.2 180.4 965.5
9 855.0 159.6 1014.6 875.9 157.8 1033.7 860.5 163.4 1023.9 836.3 172.2 1008.6 810.8 181.7 992.5
10 878.6 161.2 1039.8 902.4 159.1 1061.5 886.9 164.7 1051.5 862.5 173.6 1036.0 836.5 183.2 1019.7
11 902.1 162.9 1065.0 929.3 160.3 1089.6 913.5 166.0 1079.5 888.9 174.9 1063.8 862.8 184.5 1047.3
12 925.6 164.6 1090.3 954.0 161.5 1115.5 940.2 167.3 1107.5 915.4 176.3 1091.7 889.0 186.0 1075.0
13 949.2 166.3 1115.5 982.7 162.9 1145.6 966.9 168.7 1135.5 941.9 177.7 1119.6 915.2 187.4 1102.7
14 972.7 168.0 1140.7 1009.1 164.2 1173.2 993.2 170.0 1163.2 968.3 179.1 1147.5 941.5 188.9 1130.4
15 996.2 169.7 1166.0 1034.8 165.2 1200.0 1019.1 171.1 1190.2 993.4 180.3 1173.8 966.0 190.2 1156.2
3412
5 816.4 162.5 978.9 827.6 163.1 990.7 812.1 168.8 980.9 788.2 177.7 966.0 762.9 187.4 950.3
6 841.7 164.3 1005.9 854.9 164.4 1019.2 839.2 170.0 1009.3 814.7 179.2 993.9 789.0 188.9 977.9
7 866.9 166.1 1033.0 882.8 165.5 1048.3 866.5 171.4 1037.9 841.7 180.5 1022.2 815.5 190.4 1005.9
8 892.2 167.9 1060.1 911.5 166.5 1078.0 895.3 172.4 1067.7 869.3 181.9 1051.1 842.4 191.9 1034.3
9 917.4 169.7 1087.1 939.8 167.9 1107.6 923.3 173.8 1097.0 897.3 183.2 1080.5 870.0 193.3 1063.2
10 942.7 171.5 1114.2 968.2 169.2 1137.4 951.6 175.2 1126.7 925.4 184.6 1110.0 897.6 194.8 1092.4
11 967.9 173.3 1141.2 997.0 170.5 1167.6 980.1 176.6 1156.7 953.7 186.1 1139.8 925.7 196.3 1122.0
12 993.2 175.1 1168.3 1023.6 171.8 1195.3 1008.7 178.0 1186.7 982.1 187.6 1169.7 953.9 197.8 1151.7
13 1018.4 176.9 1195.3 1054.4 173.3 1227.7 1037.4 179.4 1216.8 1010.6 189.0 1199.6 982.0 199.4 1181.4
14 1043.7 178.7 1222.4 1082.7 174.6 1257.3 1065.7 180.8 1246.5 1039.0 190.6 1229.5 1010.2 200.9 1211.1
15 1068.9 180.5 1249.4 1110.3 175.7 1286.0 1093.4 182.0 1275.4 1065.9 191.8 1257.8 1036.4 202.3 1238.8
3602
5 871.9 172.2 1044.1 883.9 172.9 1056.8 867.3 178.9 1046.2 841.8 188.4 1030.2 814.8 198.6 1013.4
6 898.9 174.1 1073.0 913.0 174.2 1087.2 896.3 180.2 1076.5 870.1 189.9 1060.0 842.7 200.2 1042.8
7 925.8 176.0 1101.9 942.8 175.4 1118.3 925.4 181.7 1107.0 898.9 191.4 1090.2 871.0 201.8 1072.7
8 952.8 178.0 1130.8 973.5 176.5 1150.0 956.1 182.7 1138.8 928.4 192.8 1121.1 899.7 203.4 1103.1
9 979.8 179.9 1159.6 1003.7 177.9 1181.6 986.0 184.2 1170.2 958.3 194.2 1152.5 929.1 204.9 1134.0
10 1006.7 181.8 1188.5 1034.0 179.3 1213.4 1016.3 185.6 1201.9 988.3 195.7 1184.0 958.6 206.5 1165.1
11 1033.7 183.7 1217.4 1064.8 180.7 1245.5 1046.8 187.1 1233.9 1018.6 197.2 1215.8 988.7 208.0 1196.7
12 1060.7 185.6 1246.3 1093.2 182.0 1275.2 1077.3 188.6 1265.9 1048.9 198.8 1247.7 1018.7 209.7 1228.4
13 1087.6 187.5 1275.2 1126.1 183.6 1309.7 1107.9 190.1 1298.1 1079.3 200.4 1279.7 1048.8 211.3 1260.1
14 1114.6 189.4 1304.0 1156.3 185.1 1341.4 1138.2 191.6 1329.8 1109.6 202.0 1311.6 1078.9 212.9 1291.8
15 1141.6 191.4 1332.9 1185.8 186.2 1372.0 1167.8 192.9 1360.6 1138.4 203.3 1341.7 1106.9 214.4 1321.4
4212
5 933.3 196.8 1130.1 946.1 197.5 1143.6 928.4 204.4 1132.8 901.1 215.2 1116.3 872.1 227.0 1099.1
6 962.1 199.0 1161.1 977.3 199.0 1176.3 959.3 205.9 1165.3 931.3 217.0 1148.3 902.0 228.8 1130.7
7 991.0 201.2 1192.2 1009.2 200.4 1209.6 990.5 207.6 1198.1 962.1 218.7 1180.8 932.3 230.5 1162.8
8 1019.9 203.4 1223.2 1042.0 201.7 1243.7 1023.4 208.8 1232.2 993.7 220.3 1214.0 963.0 232.4 1195.4
9 1048.7 205.5 1254.3 1074.3 203.3 1277.6 1055.4 210.4 1265.9 1025.8 221.9 1247.7 994.5 234.1 1228.6
10 1077.6 207.7 1285.3 1106.8 204.9 1311.7 1087.8 212.1 1299.9 1057.9 223.6 1281.5 1026.1 236.0 1262.0
11 1106.5 209.9 1316.4 1139.8 206.5 1346.3 1120.4 213.8 1334.3 1090.3 225.4 1315.6 1058.2 237.7 1295.9
12 1135.3 212.1 1347.4 1170.1 208.0 1378.1 1153.1 215.5 1368.7 1122.7 227.1 1349.9 1090.4 239.6 1330.0
13 1164.2 214.3 1378.5 1205.3 209.8 1415.2 1185.9 217.3 1403.2 1155.3 228.9 1384.2 1122.6 241.5 1364.0
14 1193.0 216.5 1409.5 1237.7 211.5 1449.1 1218.3 219.0 1437.2 1187.7 230.8 1418.5 1154.8 243.3 1398.2
15 1221.9 218.7 1440.6 1269.2 212.8 1482.0 1250.0 220.4 1470.3 1218.5 232.3 1450.8 1184.8 245.0 1429.9
4602
5 1009.0 207.4 1216.4 1022.8 208.2 1231.0 1003.7 215.5 1219.2 974.1 226.9 1201.0 942.8 239.3 1182.1
6 1040.2 209.7 1249.9 1056.5 209.8 1266.3 1037.1 217.1 1254.2 1006.9 228.7 1235.6 975.1 241.1 1216.2
7 1071.4 212.0 1283.4 1091.0 211.3 1302.3 1070.8 218.8 1289.6 1040.2 230.5 1270.7 1007.9 243.0 1250.9
8 1102.6 214.4 1316.9 1126.5 212.6 1339.1 1106.4 220.1 1326.5 1074.3 232.2 1306.5 1041.1 244.9 1286.1
9 1133.8 216.7 1350.4 1161.4 214.3 1375.7 1141.0 221.8 1362.9 1109.0 233.9 1342.9 1075.1 246.8 1321.9
10 1165.0 219.0 1383.9 1196.6 216.0 1412.6 1176.0 223.6 1399.6 1143.6 235.7 1379.3 1109.3 248.7 1358.0
11 1196.2 221.3 1417.5 1232.2 217.7 1449.9 1211.3 225.4 1436.7 1178.7 237.6 1416.2 1144.0 250.6 1394.6
12 1227.4 223.6 1451.0 1265.0 219.3 1484.3 1246.7 227.2 1473.9 1213.8 239.4 1453.2 1178.8 252.5 1431.4
13 1258.6 225.9 1484.5 1303.1 221.2 1524.3 1282.1 229.0 1511.1 1249.0 241.3 1490.3 1213.6 254.5 1468.1
14 1289.8 228.2 1518.0 1338.0 222.9 1561.0 1317.1 230.8 1547.9 1284.0 243.3 1527.3 1248.5 256.5 1505.0
15 1321.0 230.5 1551.5 1372.2 224.3 1596.4 1351.3 232.3 1583.6 1317.3 244.9 1562.2 1280.9 258.3 1539.2
4802
5 1084.6 218.1 1302.7 1099.5 218.9 1318.5 1079.0 226.5 1305.5 1047.2 238.5 1285.8 1013.6 251.6 1265.1
6 1118.2 220.5 1338.7 1135.8 220.6 1356.4 1114.9 228.2 1343.2 1082.4 240.4 1322.8 1048.3 253.5 1301.8
7 1151.7 222.9 1374.7 1172.9 222.1 1395.0 1151.2 230.1 1381.2 1118.2 242.3 1360.5 1083.5 255.5 1339.0
8 1185.3 225.4 1410.6 1211.0 223.5 1434.5 1189.4 231.4 1420.8 1154.9 244.1 1399.0 1119.2 257.5 1376.8
9 1218.8 227.8 1446.6 1248.5 225.3 1473.8 1226.6 233.2 1459.8 1192.2 245.9 1438.0 1155.8 259.4 1415.2
10 1252.4 230.2 1482.6 1286.3 227.1 1513.4 1264.2 235.1 1499.3 1229.4 247.8 1477.2 1192.5 261.5 1454.0
11 1285.9 232.6 1518.5 1324.6 228.9 1553.5 1302.2 237.0 1539.1 1267.1 249.8 1516.8 1229.9 263.4 1493.3
12 1319.5 235.0 1554.5 1359.9 230.5 1590.4 1340.2 238.9 1579.0 1304.8 251.7 1556.6 1267.3 265.5 1532.7
13 1353.0 237.5 1590.5 1400.9 232.5 1633.4 1378.2 240.8 1619.0 1342.6 253.7 1596.4 1304.6 267.6 1572.2
14 1386.6 239.9 1626.5 1438.4 234.4 1672.8 1415.9 242.7 1658.5 1380.3 255.7 1636.1 1342.1 269.7 1611.8
15 1420.1 242.3 1662.4 1475.1 235.8 1710.9 1452.7 244.2 1696.9 1416.1 257.5 1673.6 1377.0 271.6 1648.5
