4D-Link DIR-412 User Manual
Section 1 - Product Overview
WAN Mode/3G Router Mode Switch
Use this switch to change between
WAN mode and 3G Router mode.
Power Receptor
Receptor for the supplied power
adapter.
Reset
Pressing the Reset button restores the router to
its original factory default settings.
Ethernet Port
In WAN mode the Ethernet port is used to connect
to your WAN connection. In 3G mode the Ethernet
port is used to connect to your LAN connection.
