Chapter 11 Description of Parameter Settings|C200 Series
11-63
loss of the ACI signal is recovered or drive is stop.
Multi-function Output 1 (AFM1)
Factory Setting: 0
Multi-function Output 2 (AFM2)
Factory Setting: 0
Settings 0~23
Function Chart
Settings Functions Descriptions
0 Output frequency (Hz) Max. frequency Pr.01-00 is regarded as 100%.
1 Frequency command (Hz) Max. frequency Pr.01-00 is regarded as 100%.
2 Motor speed (Hz) 600Hz is regarded as 100%
3 Output current (rms) (2.5 X rated current) is regarded as 100%
4 Output voltage (2 X rated voltage) is regarded as 100%
5 DC Bus Voltage 450V (900V)=100%
6 Power factor -1.000~1.000=100%
7 Power Rated power is regarded as 100%
8 Output torque Full-load torque is regarded as 100%
9 AVI 0~10V=0~100%
10 ACI 0~20mA=0~100%
11 AUI -10~10V=0~100%
12 q-axis current (Iq) (2.5 X rated current) is regarded as 100%
13 q-axis feedback value (Iq) (2.5 X rated current) is regarded as 100%
14 d-axis current (Id) (2.5 X rated current) is regarded as 100%
15 d-axis feedback value (Id) (2.5 X rated current) is regarded as 100%
16 q-axis voltage (Vq) 250V (500V) =100%
17 d-axis voltage(Vd) 250V (500V) =100%
18 Torque command Rated torque is regarded as 100%
19 Reserved
20 Output for CANopen control
For CANopen analog output
21 RS485 analog output
For communication output (CMC-MOD01, CMC-EIP01,
CMC-PN01, CMC-DN01)
22
Reserved
23 Constant voltage/current output
Pr.03-32 and Pr.03-33 controls voltage/current output
level
0~100% of Pr.03-32 corresponds to 0~10V of AFM1.
Gain of Analog Output 1 (AFM1)
Factory Setting: 100.0
Gain of Analog Output 2 (AFM2)
Factory Setting: 100.0
Settings 0~200.0%
