Chapter 7 Optional Accessories |C200 Series
7-4
Non-fuse Circuit Breaker
Comply with UL standard: Per UL 508, paragraph 45.8.4, part a,
The rated current of the breaker shall be 2~4 times of the maximum rated input current of AC motor
drive.
1-phase 230V
Model Recommended non-fuse breaker (A)
VFD004CB21A-20/-21/-21M 15
VFD007CB21A-20/-21/-21M 20
VFD015CB21A-20/-21/-21M 30
VFD022CB21A-20/-21/-21M 50
3-phase 230V
Model Recommended non-fuse breaker (A)
VFD004CB23A-20/-21/-21M 10
VFD007CB23A-20/-21/-21M 15
VFD015CB23A-20/-21/-21M 20
VFD022CB23A-20/-21/-21M 30
VFD037CB23A-20/-21/-21M 40
3-phase 460V
Model Recommended non-fuse breaker (A)
VFD007CB43A-20/-21/-21M 10
VFD015CB43A-20/-21/-21M 10
VFD022CB43A-20/-21/-21M 15
VFD037CB43A-20/-21/-21M 20
VFD040CB43A-20/-21/-21M 20
VFD055CB43A-20/-21/-21M 30
VFD075CB43A-20/-21/-21M 40
