Chapter 11 Description of Parameter Settings|C200 Series
11-88
62: Decel. Energy Backup Error (dEb)
63: Slip error (oSL)
64: Electromagnet switch error (ryF)
65 : PG Card Error (PGF5)
66-78: Reserved
79: Uocc U phase over current (Detection begins as RUN is pressed,
software protection)
80: Vocc V phase over current (Detection begins as RUN is pressed,
software protection)
81: Wocc W phase over current (Detection begins as RUN is pressed,
software protection)
82: OPHL U phase output phase loss
83: OPHL Vphase output phase loss
84: OPHL Wphase output phase loss
85~100: Reserved
101: CGdE CANopen software disconnect1
102: CHbE CANopen software disconnect2
103: CSYE CANopen synchronous error
104: CbFE CANopen hardware disconnect
105: CIdE CANopen index setting error
106: CAdE CANopen slave station number setting error
107: CFrE CANopen index setting exceed limit
108~110: Reserved
111: InrCOM Internal communication overtime error
When the fault occurs and force stopping, it will record in this parameter.
At stop with low voltage Lv (LvS warn, no record). During operation with mid-low voltage Lv (LvA,
Lvd, Lvn error, will record).
Setting 62: when dEb function is enabled, the drive will execute dEb and record to the Pr.06-17 to
Pr.06-22 simultaneously.
Fault Output Option 1
Fault Output Option 2
Fault Output Option 3
Fault Output Option 4
Factory Setting: 0
Settings 0 to 65535 sec (refer to bit table for fault code)
These parameters can be used with multi-function output (set to 35-38) for the specific
requirement. When the fault occurs, the corresponding terminals will be activated (It needs
to convert binary value to decimal value to fill in Pr.06-23 to Pr.06-26).
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
Fault Code
current Volt. OL SYS FBK EXI CE
0: No fault
1: Over-current during acceleration (ocA) ●
