Chapter 14 PLC Function |C200 Series
14-24
Special
M
Function
Read(R)/
Write(W)
M1023 Divisor is 0
Read only
M1024 Reserved
-
M1025 RUN(ON) / STOP(OFF) the AC motor drive
Read/Write
M1026 The operation direction of the AC motor drive (FWD: OFF, REV: ON)
Read/Write
M1027 AC motor drive reset
Read/Write
M1028
~
M1039
Reserved
-
M1040 Power On
Read/Write
M1041 Reserved
-
M1042 Quick stop
Read/Write
M1043 Reserved
-
M1044 Halt
Read/Write
M1045
~
M1051
Reserved
-
M1052 Freuqency Lock
Read/Write
M1053
~
M1055
Reserved
-
M1056 Power on ready
Read only
M1057 Reserved
-
M1058 On quick stopping
Read only
M1059
~
M1062
Reserved
-
M1063 Target torque attained
Read only
M1064
~
M1071
Reserved
Read only
M1072
~
M1079
Reserved
Read/Write
M1073
~
M1079
Reserved
Read only
14.5.3 Special Registers
Special D
Function
Read(R)/
Write(W)
D1000
Reserved -
D1001
PLC firmware version
Read only
D1002
Program capacity Read only
D1003
Checksum Read only
D1004
~
D1009
Reserved -
D1010
Present scan time (Unit: 0.1ms) Read only
