Chapter 6 Control Terminals|C200 Series
6-2
3. Put back the cover then fasten tightly the screw. Screw torque (M3): 6-8Kg-cm(5.2-6.9lb-in.)
Control Terminal the sketch map
MI1+24V
COM
FWD MI5
MI3
ACI
AUI
AFM1
MI7
MI4
DCM
REV MI2 MI8MI6ACM+10VAFM2
SG-
SG+
RA2 RC2RB1 RC1RA1
B
485
120
Ω
OPEN
DFM2
DCM
AVI
DFM1
Frame A0
ACI
AVI
ON
2
0-10V 0/4-20mA
setting of terminal resistor
MI1+24V
COM
FWD MI5
MI3
ACI
AUI
AFM1
MI7
MI4
DCM
REV MI2 MI8MI6ACM+10V
AFM2
SG-
SG+
RA2 RC2RB1 RC1RA1
A
B
485
120
Ω
OPEN
DFM2
DCM
AVI
DFM1
Frame A
ACI AVI
ON
2
0-20mA
4-20mA
0-10V
setting of
terminal resistor
Specifications of Control Terminal
Wire Gauge: 26~16AWG（0.1281-1.318mm
2
）,
Torque: (A) 5kg-cm [4.31Ib-in.] (0.49Nm) (As shown in figure above)
(B) 8kg-cm [6.94Ib-in.] (0.78Nm) (As shown in figure above)
