Chapter 10 Summary of Parameter Settings|C200 Series
10-10
Parameter Explanation Settings
Factory
Setting
02-51
Status of Multi-function
Output Terminal
Monitor the status of multi-function output terminals
Read
only
02-52
Display External Output
terminal occupied by PLC
Monitor the status of PLC input terminals
Read
only
02-53
Display Analog Input
Terminal occupied by PLC
Monitor the status of PLC output terminals
Read
only
02-54
Display the Frequency
Command Executed by
External Terminal
Read only
Read
only
02-55 Digital Output Gain (DFM2) 0~106 1
