Chapter 15 Suggestions and Error Corrections for Standard AC Motor Drives |C200 Series

15-11

15-7 Multi-function Input/Output Terminals Problem

Multi-function input/output terminal errors are generally caused by over usage of terminals and not

following specifications. Please be aware of the possible damages that errors on multi-function

input/output terminals may cause to your drives:

1. Input/output circuit may burns out when the terminal usage exceeds its limit.

Solution:

Refer to the user manual for multi-function input output terminals usage and follow the specified

voltage and current. DO NOT exceed the specification limits.
