Chapter 7 Optional Accessories|C200 Series
7-15
RJ45 Extension Lead for Digital Keypad
(Designed only for KEYPAD，NOT for CANopen communication)
Part # Description
CBC-K3FT 3 feet RJ45 extension lead (approximately 0.9m)
CBC-K5FT 5 feet RJ45 extension lead (approximately 1.5 m)
CBC-K7FT 7 feet RJ45 extension lead (approximately 2.1 m)
CBC-K10FT 10 feet RJ45 extension lead (approximately 3 m)
CBC-K16FT 16 feet RJ45 extension lead (approximately 4.9 m)
