Chapter 14 PLC Function |C200 Series

14-52

API

25 D

DEC

Decrement: BIN minus 1

Bit Devices Word Devices

X Y M K H KnX KnY KnM T C D

＊＊＊＊＊

Operands: none

16-bit command (3 STEPS)

DEC

DECP

32-bit command (5 STEPS)

－－－－

Flag signal: none

Explanation

D: Destination

1. If the command is not a pulse execution type, the content in the designated

device D will minus “1” in every scan period whenever the instruction is

executed.

2. This instruction adopts pulse execution instructions (DECP).

3. In 16-bit operation, -32,768 minuses 1 and obtains 32,767. In 32-bit operation,

-2,147,483,648 minuses 1 and obtains 2,147,483,647.

Example

When X0 goes from Off to On, the content in D0 minuses 1 automatically.

DECP D0
