Chapter 10 Summary of Parameter Settings|C200 Series
10-31
Parameter Explanation Settings
Factory
Setting
11-29 Torque Offset Setting 0~100% 0.0
11-30 High Torque Offset 0~100% 30.0
11-31 Middle Torque Offset 0~100% 20.0
11-32 Low Torque Offset 0~100% 10.0
11-33
Source of Torque
Command
0: Digital keypad
1: RS-485 communication (Pr.11-34)
2: Analog input (Pr.03-00)
3: CANopen
0
11-34 Torque Command -100.0~+100.0% (Pr.11-27=100%) 0.0
11-35
Filter Time of Torque
Command
0.000~1.000sec 0.000
11-36 Speed Limit Selection
0: Set by Pr.11-37 (Forward speed limit) and Pr.11-38
(Reverse speed limit)
1: Set by Pr.11-37,11-38 and Pr.00-20 (Source of
Master Frequency Command)
2: Set by Pr.00-20 (Source of Master Frequency
Command).
0
11-37
Forward Speed Limit
(torque mode)
0~120% 10
11-38
Reverse Speed Limit
(torque mode)
0~120% 10
11-39
Zero Torque Command
Mode
0: Torque mode
1: Speed mode
0
