Chapter 11 Description of Parameter Settings|C200 Series
11-90
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
Fault Code
current Volt. OL SYS FBK EXI CE
40: Auto tuning error (AUE) ●
41: PID feedback loss (AFE) ●
42: PG feedback error (PGF1) ●
43: PG feedback loss (PGF2) ●
44: PG feedback stall (PGF3) ●
45: PG slip error (PGF4) ●
46: Reserved
47: Reserved
48: Analog current input loss (ACE) ●
49: External fault input (EF) ●
50: Emergency stop (EF1) ●
51: External Base Block (bb) ●
52: Password error (PcodE) ●
53: Reserved
54: Communication error (CE1) ●
55: Communication error (CE2) ●
56: Communication error (CE3) ●
57: Communication error (CE4) ●
58: Communication Time-out (CE10) ●
59: Reserved
60: Brake transistor error (bF) ●
61: Y-connection/△-connection switch error
(ydc)
●
62: Decel. Energy Backup Error (dEb) ●
63: Slip error (oSL) ●
64: Electromagnet switch error (ryF) ●
65 : PG Card Error (PGF5) ●
66-78: Reserved
79: U phase over current (Uocc) ●
80: V phase over current (Vocc) ●
81: W phase over current (Wocc) ●
82: OPHL U phase output phase loss ●
83: OPHL Vphase output phase loss ●
84: OPHL Wphase output phase loss ●
85~100: Reserved
101: CGdE CANopen software disconnect1 ●
102: CHbE CANopen software disconnect2 ●
103: CSYE CANopen synchronous error ●
