Chapter 11 Description of Parameter Settings|C200 Series
11-93
Drive Status at Malfunction
Factory Setting: Read only
Settings 0000H~FFFFh
When malfunction occurs, please check the drive status (communication address 2119H). If
malfunction happens again, the previous record will be overwritten by this parameter.
Reserved
Reserved
Treatment to Output Phase Loss Detection (OPHL)
Factory Setting: 3
Settings 0: Warn and keep operating
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
Pr.06-45 defines how the drive will operates when output phase loss occur.
Deceleration Time of Output Phase Loss
Factory Setting:0.500
Settings 0.000~65.535 sec
Current Bandwidth
Factory Setting:1.00
Settings 0.00~100.00%
DC Brake Time of Output Phase Loss
Factory Setting:0.000
Settings 0.000~65.535 sec
Reserved
Time for Input Phase Loss Detection
Factory Setting:0.20
Settings 0.00~600.00 sec
Reserved
Ripple of Input Phase Loss
Factory Setting:30.0 / 60.0
Settings 230V Series: 0.0~160.0 Vdc
460V Series: 0.0~320.0 Vdc
