Chapter 9 Digital Keypad|C200 Series
9-2
External Fault.
Display “End” for approximately 1 second if input has been accepted by pressing
key. After a parameter value has been set, the new value is automatically
stored in memory. To modify an entry, use the
and keys.
Display “Err”, if the input is invalid.
NOTE
When the setting exceeds 99.99 for those numbers with 2 decimals (i.e. unit is 0.01), it will only display 1
decimal due to 4-digital display.
