ROMED8HM3
6 7
English
No. Description
1 ermal Sensor Header (TR1)
2 Serial Port Header (COM1)
3 PCI Express 4.0 x16 Slot (PCIE1)
4 M.2 Socket (M2_1) (Type 2230 / 2242 / 2260 / 2280 / 22110)
5 M.2 Socket (M2_2) (Type 2230 / 2242 / 2260 / 2280 / 22110)
6 TPM Header (TPM1)
7 NVDIMM Power Mode Jumper (NV12V_4)
8 NVDIMM Power Mode Jumper (NV12V_2)
9 Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1)
10 2 x 288-pin DDR4 DIMM Slots (DDR4_F1, DDR4_H1)*
11 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_G1)*
12 Slimline NVMe x8 Connector (SLIM6)
13 Slimline NVMe x8 Connector (SLIM5)
14 Slimline NVMe x8 Connector (SLIM4)
15 SATA SGPIO Connector (SATA_SGPIO2)
16 CM Board Standby Power Header (CM_SB_L)
17 USB 3.1 Gen1 Header (USB3_3_4)
18 PSU SMBus (PSU_SMB1)
19 Non Maskable Interrupt Button (NMI_BTN1)
20 System Fan Connector (FAN4)
21 ATX 12V Power Connector (ATX12V1)
22 System Fan Connector (FAN3)
23 Front Panel Board Header (J2)
24 Vertical Type A USB 2.0 (USB_1)
25
PWM Conguration Header (PWM_CFG1)
26 Speaker Header (SPEAKER1)
27 Auxiliary Panel Header (AUX_PANEL1)
28 System Panel Header (PANEL1)
29 ATX 12V Power Connector (ATX12V2)
30 System Fan Connector (FAN1)
31 System Fan Connector (FAN2)
32 Mini SAS HD Connector (SATA_0_7)
33 CM Board Standby Power Header (CM_SB_R)
34 SATA SGPIO Connector (SATA_SGPIO1)
