10 11
English
No. Item Status Description
1 FAN_LED4 Amber FAN4 failed
2 FAN_LED3 Amber FAN3 failed
3 SB_PWR1 Green STB PWR ready
4 FAN_LED2 Amber FAN1 failed
5 FAN_LED1 Amber FAN2 failed
6 BMC_LED1 Green BMC heartbeat LED
