Appendix TPM Module Support List
is motherboard supports the following TPMs (Trusted Platform Module).
TPM Module Version Type Brand P/N
TPM-S TPM 1.2 17PIN Nuvoton 80-CXG2C0-1B12
TPM2-S TPM 2.0 17PIN Nuvoton 80-CXG5H0-1A21
TPM2-SLI TPM 2.0 13PIN Inneon 80-SC01T0-1A02
*Please refer to our website for the latest support list.
