ASRock ROMED8HM3 [9/77] English
![ASRock ROMED8HM3 [9/77] English](/views2/1694142/page9/bg9.png)
ROMED8HM3
2 3
English
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 512MB
Rear Panel I/O
VGA Port 1 (Mini DisplayPort)*
*Not supported for the standard Mini DisplayPort connection.
USB 3.0 Port 2
LAN Port 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED)
Front Panel 1
TPM Header 1
IPMB Header 1
Fan Header 4 Fans x 6-pin
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
ATX Power 2 x (8-pin)
CM SB Power 2
SATA SGPIO 2
OCulink 1
BMC SMB 1
PSU SMB 1
TR 1
NMI Button 1
COM Header 1
Speaker(4pin) 1
ClearCMOS 1
CPU1_HSBP1 1
CM_SB_L 1
CM_SB_R 1
OH/FanFail
LED
4 (only Fan Fail LED)
System BIOS
BIOS Ty pe 64MB AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
