entries which utilize a multiple-event counter. e value ranges from 0 to 99 minutes.
Log EFI Status Code
Enable or disable the logging of EFI Status Codes as OEM reserved type E0 (if not already
converted to legacy).
Convert EFI Status Codes to Standard Smbios Type
Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all
may be translated).
View Smbios Event Log
Press <Enter> to view the Smbios Event Log records.
All values changed here do not take eect until computer is restarted.
