2 3
English
1.2 Specications
ROMED8HM3
MB Physical Status
Form Factor Half Width
Dimension 6.5’’ x 17’’ (16.5 cm x 43.1 cm)
Processor System
CPU AMD EPYC™ 7002/7001 Series Processor Family
Socket Single Socket SP3 (LGA4094)
Chipset N/A
System Memory
Type - Eight Channel DDR4 memory technology
- Supports DDR4 RDIMM, LRDIMM
DIMM Size Per
DIMM
- RDIMM: 64GB*,32GB, 16GB, 8GB
- LRDIMM: 128GB**, 64GB*, 32GB
- NV DIMM:32GB***
*64GB: wait for the device to be validated
**128GB: wait for the device to be validated
***Wait for the device to be validated
DIMM
Frequency
- RDIMM: 3200MHz
- LRDIMM: 3200MHz
- NVDIMM: 2666MHz*
*Wait for the device to be validated
Voltage 1.2V
Expansion Slot
PCIe 3.0/4.0 x16 PCIE1: Gen3/Gen4 x16 link
PCIe 3.0/4.0 x24 PCIE2: Gen3/Gen4 x24 link
Storage
SATA Controller 8 x SATA3 (8 from 2x mini SAS HD connector, 2 for M.2 slots)
M.2 Slot 2 (2230/2242/2260/2280/22110, SATA3 x1 or PCIE Gen4 x4)
Slimline SLIM1: PCIe Gen4 x8
SLIM2: PCIe Gen4 x8
SLIM3: PCIe Gen4 x8
SLIM4: PCIe Gen4 x8
SLIM5: PCIe Gen4 x8
SLIM6: PCIe Gen4 x8
Mezzanine 1 x OCP3.0 4C+ SFF(PCIe x16)
Ethernet
Interface N/A
LAN 1 x RJ45 Dedicated IPMI LAN port
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
