E3C246D4U / E3C242D4U / C246M WS
4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make sure that
the “Wake on Magic Packet from power o state” is enabled in Device Manager > Intel® Ethernet
Connection > Power Management. And the “PCI Devices Power On” is enabled in UEFI SETUP
UTILITY > Advanced > ACPI Conguration. Aer that, onboard LAN1&2 can wake up S5 under
OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Windows® Hard-
ware Quality Lab (WHQL) certication tests. If you install the drivers only, it will pass the WHQL
tests.
System BIOS
BIOS Ty pe 256 Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/PCH Temperature Sensing
- MB/Card Side/TR1 Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU
Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage E3C246D4U / E3C242D4U:
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, VCCM,
VPPM, VCCIO, VCCSA, VCCST_SFR, V1.0M, 3VSB, 5VSB,
VBAT
C246M WS:
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, VCCM,
VCCIO, VCCSA, VCCST_SFR, V1.0M, 3VSB
Support OS
OS Microso® Windows®
E3C246D4U / E3C242D4U:
- Server 2016 (64 bit)
C246M WS:
- Windows 10 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.9 (64 bit) / 7.4 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (64 bit) /
12 SP3 (64 bit)
- Ubuntu 15.10 (64 bit) / 16.04 (64 bit)
*Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
