E3C246D4U / E3C242D4U / C246M WS
8 9
English
No. Description
34 Chassis ID2 Jumper (CHASSIS_ID2)
35 Chassis ID1 Jumper (CHASSIS_ID1)
36 ermal Sensor Header (TR1)
37 M.2 Socket (M2_1) (Type 2230/2242/2260/2280)*
38 Rear Fan Connector (REAR_FAN2)
39 CPU PECI Mode Jumper (PECI1)
40 Rear Fan Connector (REAR_FAN1)
41 Non Maskable Interrupt Button (NMI_BTN1)
*e M.2 slot (M2_1) is shared with the SATA_0 connector. When M2_1 is populated with a M.2 SATA3/
PCIE3.0(x4 or x2) module, SATA_0 is disabled.
